DUAL SHAFT INDUSTRIAL SHREDDERS

Reliable

Performance-Driven Products

Monthly Retainer

Dual Shaft Industrial Shredders

Dual Shaft Industrial Shredders incorporate a pair of counter-rotating shafts and are exceptionally well-suited for an array of tasks involving destruction and primary size reduction. These Industrial shredders find frequent application in scenarios such as document disposal, e-scrap handling, product disintegration, as well as preliminary processing of materials like tissue, wood scrap, tires, counterfeit items, household goods, and automotive components to facilitate subsequent processing stages.
These Industrial shredders provide a diverse range of cutter configurations that effectively process materials, preventing blockages and ensuring a consistently high throughput. In cases where the material being Industrial shredded possesses a smooth exterior, a ram might be employed to aid cutter engagement. Operating at low speeds but yielding high torque, Dual Shaft Industrial Shredders belong to the realm of industrial machinery, promoting reduced heat generation and diminished dust production compared to their high-speed, low-torque counterparts.

FEATURES

Custom in-feed hoppers
Auto reversing PLC driven controls
Cutter configurations are application specific
In-line planetary drives for maximum transfer of torque
Auto shaft reversal improves reliability by preventing overfeeding and damage from Industrial unshreddable objects
Bearing protection prevents Industrial shredded contaminants from reaching the bearings
Built to order for a seamless fit in your system
UL/CSA rated panels are available
Individual cleaning fingers

MODEL
DS-15
DS-20
DS-30
DS-55
DS-60
DS-75
DS-125
DS-150

CHAMBER SIZE
16 in x 21 in
24.25 in x 26.5 in
23 in x 36 in
24.25 in x 26.5 in
28 in x 38 in
31 in x 48 in
35 in x 50 in
39 in x 60 in

NUMBER OF DRIVES
1
2
1
2
2
1
1
1

HORSEPOWER
10 or 15
20
30 or 40
45 or 55
55 or 60
50, 60 or 75
100 or 125
150

Dual Shaft Industrial Shredding System Design

Dual Shaft Industrial Shredding Systems are custom built according to each application’s requirements. The stated references and specifications are just guidelines for each machine. Contact an Industrial Shredders sales engineer for more information and sizing assistance for your two shaft Industrial shredders.
